Aluminum round tube aluminum fin heat exchanger

(0) Reviews

The Aluminum Round Tube Aluminum Fin Heat Exchanger features internally threaded tubes to enhance heat transfer efficiency. The threaded structure increases the internal heat transfer area by 20%–25%, improves fluid turbulence, and enhances evaporation and condensation performance. Made from high-quality aluminum materials, it offers lightweight design, corrosion resistance, excellent recyclability, and reduced electrochemical corrosion. Suitable for refrigeration, air conditioning, and heat pump systems.

INQUIRE NOW ADD TO CART

Product Introduction

Aluminum round tube aluminum fin heat exchanger-Design Parameters

1.Internally threaded tubes enhance heat transfer

2.Increase the heat transfer area inside the tube. The internally threaded tube can increase the area by 20%~25% compared to the smooth tube with the same outer diameter;
3.The internal thread produces spiral flow, increases the speed of the liquid film on the tube wall, and increases the mixing degree of the two-phase fluid
4.During evaporation, the thread processing surface improves the gas core production conditions, increases the number of gasification cores,and enhances boiling;
5.During condensation, the internal teeth of the internal thread pierce the liquid fi lm and penetrate into the gas phase area, increasing the contact area with the gas phase;

Aluminum round tube aluminum fin heat exchanger-Material Selection
