Long-range jet unit

Applicable Scenarios:

Suitable for large spaces where lower initial investment and reduced air conditioning system operating costs are desired; for situations where ductwork installation is not feasible or difficult in the upper space; and for high-ceilinged, large spaces where downward hot air delivery is challenging.

Especially suitable for: supermarkets, large commercial buildings, factory workshops, stadiums, swimming pools, airport waiting halls, train waiting halls, exhibition halls, lobbies, etc.

◆ Features:

In addition to the cooling, drying, heating, and humidifying functions of ordinary ceiling-mounted and cabinet-type air conditioning units, the long-range jet air conditioning unit also features the following functions and characteristics:

① Utilizes a spherical air outlet with superior jet performance as the air delivery outlet, allowing cold and hot air to be delivered over a sufficient distance.

② The air outlet direction can be selected for horizontal or vertical downward air delivery. Particularly suitable for high-ceilinged spaces, especially for downward delivery of warm air in large workshops.

③ When delivering horizontal air, the air delivery angle can be manually adjusted within a 60° range to ensure that cold and hot air reaches the desired location. ④ For vertical air delivery, the spherical nozzle is fixed in winter, delivering air vertically downwards for long distances to reach designated locations. In summer, the spherical nozzle can be adjusted within a 60°C range to simulate natural wind, avoiding the discomfort caused by cold air conducting heat, and resolving the conflict between providing hot air in winter and cold air in summer.

⑤ Electrode electrostatic air filters and nylon pre-filters are available for users to choose from. Electrode electrostatic air filters are characterized by high filtration efficiency (94% counting efficiency (2-3 1μm)), capable of replacing both coarse and medium-efficiency air filters, and have low air resistance (40Pa (0Am/s)) and low price. (Note: Slightly reduced range.)

⑥ An optional variable frequency speed control system manufactured in-house can be installed. The system automatically adjusts the air supply frequency of the air conditioning unit according to the air conditioning load, and can operate with 100% fresh air during transitional seasons.

⑦ To prevent water leakage from the air conditioning unit, the condensate drain pan is designed to have the same area as the unit's base plate.

⑧ The unit features a frame structure design, and the inspection doors are connected using special fastening connectors, employing advanced technology and facilitating maintenance.

⑨ Low-noise operation.

Model Naming：

Product Improvement Serial Number

Inlet Pipe Direction: Left Inlet: Z; Right Inlet: Y (Distinguished by facing the air outlet)

Number of Coils: 4:4 rows, 6:6 rows;

D: Ceiling-mounted;

L: Vertical;

W: Horizontal

Unit Type: Long-range Jet Unit

Rated Air Volume: Digital x 1000 m3/h

Combined Air Handling Unit
